Screens 1%
Gray / White-Pearl Gray
43 010
What sets Gray / White-Pearl Gray apart
The Screens 1% fabric Gray / White-Pearl Gray 43 010 in the color Grey prevents the penetration of heat with a fabric opening factor of 1% and still allows light to enter. This ensures protection of your privacy and still allows a certain amount of Transparency to the outside. The Gray / White-Pearl Gray fabric is compatible with the following STOBAG products: METRO, VISOMBRA, VERTICAL, UNIVERSAL, VENTOSOL.
Technical data
Fabric Properties
Protection Type
Collection
Screens 1%
Fabric material
Screens
Openness factor (%)
1
Fire protection class
B1
Pattern
Solid
Weight
(g/m2)
620
Fabric thickness (mm)
0.80
Roll width (cm)
270
Transmission values *
*
Subject to change without notice.
Light Transmission Tv (%) - front
2
Light Transmission Tv (%) - back
2
Radiation Transmission Ts (%) -
front
2.2
Radiation Transmission Ts (%) -
back
2.2
Radiation Reflection Rs (%) -
front
44.8
Radiation Reflection Rs (%) -
back
31.2
Radiation Absorption As (%) -
front
53
Radiation Absorption As (%) -
back
66.6
Details
Structure
Pattern
Frame Colors
Thanks to the wide range of colors and surfaces, the frame colors can be harmoniously matched to the fabric and its surroundings. With 8 CLASSIC- and 16 LIFESTYLE colors as well as a variety of traditional RAINBOW colors, a wide range is available that leaves nothing to be desired. All profiles and frame parts are also powder-coated and offer effective weather protection.
