Brilliant
Ladakh
22 204
What sets Ladakh apart
The Brilliant fabric Ladakh 22 204 in the color Grey is an all-weather solution and offers reliable protection thanks to its dirt and water-repellent outer impregnation and the special waterproof acrylic fabric. The Ladakh fabric is compatible with the following STOBAG products: JUMBO, PURABOX, CASABOX, TENDABOX, CAMABOX, RESOBOX, OMBRAMOBIL, BOXMOBIL, Side awnings, METRO, VISOMBRA, VERTICAL, UNIVERSAL, VENTOSOL, AIROMATIC, TARGA, ARNEX1, PERGOLINO, AZUR, SELECT, VIVO.
Technical data
Fabric Properties
Protection Type
Collection
Brilliant
Fabric material
Acrylic
UV protection class
UV97_5
Pattern
Patterned
Water column (mm)
460
Weight
(g/m2)
290
Fabric thickness (mm)
0.60
Roll width (cm)
120
Pattern width (cm)
24
Edging Tape No.
727
Transmission values *
*
Subject to change without notice.
Light Transmission Tv (%) - front
2
Light Transmission Tv (%) - back
2
Radiation Transmission Ts (%) -
front
2.3
Radiation Transmission Ts (%) -
back
2.3
Radiation Reflection Rs (%) -
front
22.7
Radiation Reflection Rs (%) -
back
22.7
Radiation Absorption As (%) -
front
75
Radiation Absorption As (%) -
back
75
Details
Structure
Pattern
Frame Colors
Thanks to the wide range of colors and surfaces, the frame colors can be harmoniously matched to the fabric and its surroundings. With 8 CLASSIC- and 16 LIFESTYLE colors as well as a variety of traditional RAINBOW colors, a wide range is available that leaves nothing to be desired. All profiles and frame parts are also powder-coated and offer effective weather protection.
