What sets Burgundy apart
The Classic fabric Burgundy 24 514 in the color Red offers first-class UV protection. Thanks to high-quality, spinneret-dyed acrylic, the fabric retains its color for a long time. Classic is available in one color, with fine, wide or multi-colored stripes and in the high-quality "Brilliant" version. The Burgundy fabric is compatible with the following STOBAG products: CASABOX, TENDABOX, VENTOSOL, AIROMATIC, TARGA, PERGOLINO, SELECT.
Technical data
Fabric Properties
Weight
(g/m2)
290
Thickness (mm)
0.60 - 0.64
Width (cm)
120
Pattern
Solid
Fabric type
Classic
Fabric material
Acrylic
Edging Tape No.
73
Protection Type
UV protection class
UV100
Water column (mm)
370
Protection Properties
Radiation Transmission Ts (%) - front
0.6
Radiation Transmission Ts (%) - back
0.6
Radiation Reflection Rs (%) - front
14.9
Radiation Reflection Rs (%) - back
14.9
Radiation Absorption As (%) - front
84.5
Radiation Absorption As (%) - back
84.5
Details
Structure
Pattern
Frame Colors
Thanks to the wide range of colors and surfaces, the frame colors can be harmoniously matched to the fabric and its surroundings. With 8 CLASSIC- and 12 LIFESTYLE colors as well as a variety of traditional RAINBOW colors, a wide range is available that leaves nothing to be desired. All profiles and frame parts are also powder-coated and offer effective weather protection.
